Copper Nickel Plates & Sheets - UNS C71500 Manufacturer & Supplier - USA Piping Solution

When your application demands reliable performance under pressure, USA Piping Solution delivers. We are a specialized manufacturer and supplier focused on high-specification materials like Copper Nickel Plates & Sheets - UNS C71500. Often referred to simply as 70/30 Copper Nickel, this alloy blend (about 70% copper, 30% nickel) offers excellent defense against corrosion, particularly standing up well in tough marine settings. It also brings good mechanical strength and is known for being readily workable during fabrication. For systems needing to handle fast-moving seawater, cope with damaging turbulence, or operate under high pressure, UNS C71500 is a trusted material choice for long service life. Here at USA Piping Solution, we maintain a solid inventory of Copper Nickel UNS C71500 Sheets and plates. We also provide expert processing services for clients across shipbuilding, power generation, chemical processing, offshore oil & gas, and other demanding sectors. Count on USA Piping Solution for your Copper Nickel Plates & Sheets - UNS C71500 requirements, delivered correctly and with quality you can depend on.

What are Copper Nickel Plates & Sheets - UNS C71500?

Put simply, Copper Nickel Plates & Sheets - UNS C71500 are flat metal products made using that specific 70/30 copper-nickel alloy recipe. The UNS C71500 designation signals the core components: copper (approx. 70%) and nickel (approx. 30%). However, the key to its enhanced capabilities lies in the deliberate additions of iron (Fe, usually 0.4-1.0%) and manganese (Mn, up to 1.0%). Far from being mere trace elements, these additions are crucial - they improve the alloy's strength and significantly boost its resistance to erosion-corrosion, a major factor in flowing seawater.

Key Attributes of C71500:

• Strong Corrosion Defense: It performs exceptionally well against general corrosion, pitting, and crevice attack in seawater and salty or brackish water. Importantly, it also resists stress corrosion cracking (SCC), a vulnerability for some other metals.
• Inherent Anti-Fouling: Like many copper-based materials, C71500 naturally discourages marine organisms from latching on. This is a big plus for maintaining heat transfer efficiency and flow in piping.
• Good Strength & Formability: It offers respectable strength – noticeably more than the 90/10 CuNi grade (C70600), especially when temperatures climb. At the same time, it retains enough ductility for practical forming operations.
• Works Well in the Shop: Standard fabrication techniques like bending, forming, welding, brazing, and soldering are all suitable for C71500. Welding, in particular, is generally straightforward.
• Built for Demanding Service: This alloy comes into its own in situations involving higher temperatures, system pressures, and rapid fluid flow where erosion can be a significant problem.

Plate vs. Sheet – What's the Difference?

The main distinction is thickness:

• Copper Nickel UNS C71500 Sheets: These are the thinner products, generally under 3/16 inch (around 4.76mm). They're often chosen when flexibility for forming complex shapes is needed or when minimizing weight is important.
• UNS C71500 Copper Nickel Plate: This term applies to the thicker material, starting at 3/16 inch (4.76mm). Plate provides the necessary structural backbone for components like pressure vessel parts, sturdy tube sheets, and other applications needing greater rigidity.

USA Piping Solution supplies both Copper Nickel 70/30 Sheets and plates, helping you source the right starting form for your specific components.

Copper Nickel Plates & Sheets - UNS C71500 Specifications

Reliability starts with meeting the right standards. The Copper Nickel Alloy Sheets and plates provided by USA Piping Solution are produced to align with recognized international specifications. This practice ensures consistency and predictable performance in your critical systems.

Technical Specifications

Our inventory typically conforms to key standards including:

• ASTM International:
• B122 / B122M: The fundamental standard for C71500 plate, sheet, strip, and rolled bar.
• B171 / B171M: A vital specification specifically covering plate and sheet intended for pressure vessels, condensers, and heat exchangers.
• B151 / B151M: Details the requirements for rod and bar forms.
• B432 / B432M: Defines C71500 when used as a protective cladding layer over steel plate.
• ASME (Boiler and Pressure Vessel Code):
• SB122 / SB171 / SB151: These are the corresponding ASME versions, enabling use in code-stamped construction.
• Military (MIL-SPEC):
• MIL-C-15726F: A frequently cited standard for C71500 in various forms, often used for naval procurement.
• Other Widely Used Standards:
• DIN 2.0882 (German std. designation: CuNi30Mn1Fe)
• EN CW354H (European Norm designation: CuNi30Mn1Fe)
• BS 2875 CN107 (An older British standard sometimes still seen)
• SAE J461, J463 (Society of Automotive Engineers standards covering copper alloys)

Meeting these established benchmarks provides a solid foundation for material selection and performance expectations.

Chemical Composition and Mechanical Properties

What makes C71500 perform the way it does? It comes down to its precise chemical balance and the resulting physical strength characteristics. USA Piping Solution ensures that our materials align with these critical parameters.

Chemical Composition (Typical, Weight %)

Looking at the typical ingredients:

Element	Symbol	Content Range (%)	Nominal (%)	Role in the Alloy
Copper	Cu	Remainder	~69.5	The primary base metal
Nickel	Ni	29.0 - 33.0	30.0	Key to corrosion resistance
Iron	Fe	0.40 - 1.0	~0.7	Improves erosion performance
Manganese	Mn	up to 1.0	~0.8	Aids processing, adds strength
Lead	Pb	up to 0.05	-	Limited as an impurity
Zinc	Zn	up to 1.0	-	Limited as an impurity

(Note: "Rem" means Remainder. Specific limits can have slight variations depending on the standard being followed.)
The controlled amounts of Nickel and Iron are particularly important for achieving good service life in marine conditions.

Mechanical Properties (Typical, Annealed Condition)

These values give insight into the material's strength and ductility:

Property	Typical Value (Imperial)	Typical Value (Metric)	What It Indicates
Tensile Strength, Ultimate	~60 ksi	~414 MPa	Maximum pulling stress
Tensile Strength, Yield	~25 ksi	~172 MPa	Stress point for permanent set
Elongation in 2"	~40 %	~40 %	How much it stretches before break
Hardness, Rockwell B	~60 HRB	~60 HRB	Resistance to surface indentation
Modulus of Elasticity	~22,000 ksi	~152 GPa	Material's inherent stiffness

(Note: These represent typical values for the soft, annealed condition. Cold working will increase strength and hardness but reduce elongation. Always refer to the specific Material Test Report (MTR) for guaranteed minimums for your material lot.)
This balance allows C71500 to be formed effectively when annealed, while other tempers provide higher strength if needed.

Types and Variations of Copper Nickel Plates & Sheets

While UNS C71500 identifies the alloy itself, the product you order will also depend on form, condition, and finish:

• Plate or Sheet: As covered, thickness is the main differentiator. Sheets (< 3/16") are thinner and more formable; Plates (≥ 3/16") are thicker, offering structural integrity.
• Temper (Material Condition):
• Annealed (O61): The softest condition, offering maximum ductility. Ideal if significant forming or welding is planned. Common for both forms.
• Hot Rolled (M20): A frequent starting condition for plates, providing a good baseline combination of properties.
• Cold Rolled (H-Tempers): Used mainly to strengthen sheets (e.g., H02 - Half Hard). This makes the material harder but less easy to form.
• Surface: The standard finish comes from the rolling process. If you need a specific finish like polished or brushed, let us know.
• Clad Option: It's possible to get UNS C71500 Copper Nickel Plate bonded to a steel base plate (following ASTM B432). This combines C71500's corrosion barrier with the cost-effectiveness and strength of steel backing.

The USA Piping Solution team can help you determine which specific product configuration best matches your project's needs.

Applications and Industries Served

Which industries rely most on Copper Nickel Plates & Sheets - UNS C71500? Its particular set of strengths makes it highly valuable in several key areas:

• Marine & Shipbuilding: This is where C71500 sees extensive use.
• Seawater piping systems (for cooling, fire suppression) are common applications.
• Condensers and heat exchangers frequently use C71500 for tube sheets, shells, and support structures.
• Desalination facilities depend on it for handling corrosive brine and seawater effectively.
• It's used for specific hull sections or protective sheathing on offshore structures.
• Valves, pump components, and various fittings exposed to the marine environment often utilize C71500.
• Oil & Gas Sector (Offshore & Onshore):
• Platform cooling systems and firewater lines benefit from its resistance.
• Refinery heat exchangers sometimes use C71500, especially when dealing with saline cooling water.
• Power Generation:
• Coastal power plants make extensive use of C71500 in condensers and heat exchangers cooled by seawater or brackish water.
• Related piping systems within these cooling loops also frequently use this alloy.
• Chemical Processing:
• Employed in certain process equipment where C71500 offers the right combination of resistance to specific chemicals and chloride environments.
• General Industrial Use:
• Building durable, high-integrity heat exchangers.
• Constructing pressure vessels for moderate conditions where excellent corrosion resistance is paramount.

USA Piping Solution has experience supplying Copper Nickel Alloy Sheets and plates to these industries, understanding their operational contexts and quality requirements.

Copper Nickel Plates & Sheets - UNS C71500 Size Chart

Getting the right dimensions is key for efficiency. USA Piping Solution stocks a variety of standard Copper Nickel Plates & Sheets - UNS C71500 sizes and provides cutting services for custom requirements. Here’s a general overview of what's typically available:

Copper Nickel UNS C71500 Sheets:

• Thickness: Often stocked in gauges from 0.050" (1.27mm) up to 0.187" (4.75mm).
• Widths: Common widths like 24" (610mm), 36" (914mm), and 48" (1219mm) are usually on hand.
• Lengths: Standard sheet lengths like 96" (2438mm), 120" (3048mm), 144" (3658mm) are typical, along with coil availability.

UNS C71500 Copper Nickel Plate:

• Thickness: Available from 3/16" (4.76mm) up to 3" (76.2mm), and sometimes thicker stock can be sourced.
• Widths: Frequently stocked widths include 48" (1219mm), 60" (1524mm), 72" (1829mm), and 96" (2438mm).
• Lengths: Standard mill lengths often run from 96" (2438mm) up to 240" (6096mm), but custom lengths are readily achieved via cutting.

Keep in Mind:

• Inventory is dynamic; please confirm current availability with us.
• Our cutting services (shear, saw, waterjet) allow you to order pieces cut close to your final dimensions, reducing your shop time and scrap.
• Materials are supplied according to standard industry dimensional tolerances.

Please contact the USA Piping Solution sales staff with your specific size needs so we can provide an accurate, up-to-date quote.

Certifications and Compliance Standards

Traceability and verified quality are non-negotiable for critical components. USA Piping Solution ensures all Copper Nickel Plates & Sheets - UNS C71500 shipments are properly documented:

• Material Test Reports (MTRs): You'll receive an MTR (or MTC) certified to EN 10204 Type 3.1 with your order. This key document provides the material's heat number, verified chemical analysis, and mechanical test results, confirming it meets the requirements of the standard you ordered (like ASTM B171 or MIL-C-15726F).
• Meeting the Specs: We confirm that the material supplied fulfills the requirements of the relevant ASTM, ASME, MIL-SPEC, or other standard designated on your purchase order.
• Quality Framework: Our internal processes follow a documented Quality Management System (mention ISO 9001 if applicable) to promote consistency and control.
• Third-Party Oversight: If your project requires it, we can coordinate with independent inspection agencies (such as DNV, ABS, Lloyd's Register, BV) for witnessed testing or verification.
• Beyond the Basics: Should you need supplementary tests (e.g., ultrasonic exams, specific corrosion evaluations), we can typically arrange these when they are clearly specified beforehand.

This diligent approach to certification provides confidence that the UNS C71500 Copper Nickel Plate and sheet you receive is fully traceable and fit for purpose in demanding service.

Why Choose USA Piping Solution for Copper Nickel Plates & Sheets - UNS C71500?

Selecting USA Piping Solution as your source for Copper Nickel Plates & Sheets - UNS C71500 makes good sense for several reasons:

• Material Know-How: We work with copper-nickel alloys regularly and understand their characteristics and best uses. We can offer informed input.
• Inventory On Hand: Our commitment to stocking C71500 often translates to faster delivery times for common sizes, helping keep your project moving.
• Quality You Can Trust: Expect materials that meet the specs, backed by thorough quality checks and complete certification (MTRs standard).
• Efficient Processing: Utilize our in-house cutting services to get plate and sheet delivered closer to your needed dimensions, saving fabrication steps and material.
• Industry Experience: We've successfully supplied C71500 into challenging sectors like marine, offshore, power, and chemical. We know the expectations.
• Responsive Support: We prioritize clear communication, dependable delivery information, and genuinely helping our customers.
• Broader Supply: We can often provide matching C71500 pipes, fittings, flanges, and bars, potentially consolidating your sourcing efforts.

Choose USA Piping Solution for reliable access to quality Copper Nickel Plates & Sheets - UNS C71500 and a supplier relationship focused on supporting your success.

Related Products

Our capabilities include a range of related corrosion-fighting materials. Ask us about:

Let us know if we can assist with these materials for your project scope.

Final Call to Action

Secure the long-term performance and reliability your critical systems require. Specify premium Copper Nickel Plates & Sheets - UNS C71500 from USA Piping Solution. Access our inventory, leverage our material knowledge, and benefit from our processing capabilities for your upcoming marine, oil & gas, power, or chemical industry projects.

Contact USA Piping Solution today - your reliable source for high-performance Copper Nickel Plates & Sheets - UNS C71500 and responsive service.

">Request Your Copper Nickel Plates & Sheets Quote Today!
