Amardeep Steel Centre serves as a key national supplier for St52 Tubes & Pipes, materials often produced following the DIN 2391 standard for seamless precision steel tubes. St52 is recognized as a higher-strength low-alloy steel, making it a frequent choice for challenging mechanical and structural tasks where load capacity beyond standard carbon grades is necessary. Our network across the United States holds significant inventories, giving you reliable access to certified St52 Tubes & Pipes. When your work demands these robust materials, backed by solid technical understanding and dependable logistics, USA Piping Solution is ready to deliver.

What are St52 Tubes & Pipes?

When engineers talk about St52 Tubes & Pipes, they're usually referring to seamless precision steel tubes made from Grade St52 steel, typically adhering to the German standard DIN 2391. This standard is all about seamless tubes built for jobs where dimensional accuracy and a clean surface are just as important as the material itself – think mechanical components, automotive parts, and precision structures. Unlike standards focused solely on pressure holding, DIN 2391, with its St52 grade, emphasizes these manufacturing qualities.

St52 steel itself stands out from basic carbon steels (like St37 within the same standard) due to its low-alloy composition. Higher levels of manganese, along with controlled carbon and silicon, give it notably better strength and toughness.

Key features to understand about these tubes:

• DIN Standard Roots: Their specifications originate from DIN 2391, ensuring they meet specific German industrial benchmarks for precision tubing. (Equivalent grades like E355 often appear under newer EN standards).
• Always Seamless: Starting from solid steel billets and piercing them means there's no weld seam. This process guarantees uniformity in the tube wall structure.
• Precision Built: These tubes are almost always cold-finished, usually through cold drawing. This finishing step achieves the tight dimensional control (OD, ID, wall thickness) and smooth surfaces that define precision tubing, often reducing later machining needs.
• Enhanced Strength: The St52 grade delivers substantially higher yield and tensile strength than plain low-carbon steels. This allows for designs that handle greater loads or potentially use less material weight. Good toughness and weldability (with proper procedures) are also part of its profile.

In short, DIN 2391 St52 Pipes become the material of choice when a project needs the dimensional exactness of precision tubing combined with the superior strength and toughness that Grade St52 steel provides. They are a workhorse for demanding St52 Steel Tubes applications.

St52 Tubing Specifications

Using St52 tubing correctly means understanding its specific technical parameters as laid out in DIN 2391. USA Piping Solution provides materials that meet these essential criteria for demanding engineering tasks.

Technical Details

Specification	Details
Governing Standard	DIN 2391 (Seamless Precision Steel Tubes) is the primary reference. Grades like E355 under EN 10305-1 are often considered equivalents. Base properties might relate to DIN 1629 or DIN 17100.
Grade Reference	St52 (Material numbers like 1.0570 or 1.0580 are related; E355 is the common EN equivalent).
Production	Seamless manufacturing is fundamental to the DIN 2391 St52 designation.
Finishing & Condition	Typically Cold Finished (Cold Drawn). The final state is indicated by condition codes: BK: As-drawn (Hard) - Maximum strength from cold work. BKS: Stress Relieved - Reduces internal stresses post-drawing. NBK: Normalized - Heat treated after drawing for a balanced combination of high strength, good toughness, and improved machinability. This is a very common condition for St52. GBK: Annealed - Fully softened (less common, sacrifices strength for ductility). BKW: Lightly cold worked after annealing.
Size Availability (OD)	DIN 2391 covers a wide range (e.g., 4mm up to 190mm), but St52 is most frequently stocked in sizes relevant to hydraulics, shafts, and structural components.
Wall Thickness	A broad range is possible, from thin (0.5mm) up to very thick walls (15mm+), depending on the OD.
Lengths	Available as standard mill random lengths (often 4-7 meters) or precision cut to specific component lengths. Mill maximums often exceed 6000mm.
Dimensional Control (Check DIN 2391 / EN 10305-1)	Precision tolerances are a defining feature, much tighter than standard pipe for OD, ID, and wall thickness. Straightness is also closely controlled.

Chemical Composition and Mechanical Properties

The noticeable step-up in strength from St52 Tubes & Pipes comes from its specific low-alloy chemistry. These chemical ingredients, combined with the manufacturing process and final heat treatment, determine its mechanical capabilities.

Chemical Makeup (% by Weight)

DIN 2391 St52 relies on increased manganese content, alongside controlled carbon and silicon, for its enhanced properties.

Element	St52 Requirement (%)	Impact on Performance
Carbon (C)	≤ 0.22	Kept moderate for strength while allowing for reasonable weldability.
Silicon (Si)	≤ 0.55	Enhances strength and helps during steel production.
Manganese (Mn)	≤ 1.60	The key element boosting strength, hardness, and particularly toughness.
Phosphorus (P)	≤ 0.025 (or 0.040)	An impurity, kept low for better toughness. (Limit varies)
Sulfur (S)	≤ 0.025 (or 0.040)	An impurity, restricted for toughness and weld quality. (Limit varies)

Compared to plain carbon steels like St35/St37, St52's chemistry provides a distinct strength advantage.

Mechanical Strength Profile (Condition is Key)

The actual strength and ductility figures for DIN 2391 St52 Pipes depend heavily on whether it's supplied as-drawn (BK) or heat-treated (NBK, BKS, GBK).

Property	BK (Cold Finished /Hard)	NBK (Normalized)	Units	What This Means
Tensile Strength	640 MPa min	490 - 630 MPa Range	MPa	The BK condition is significantly stronger; NBK offers substantial, well-controlled strength.
Yield Strength	(Implied High ~550+ MPa)	355 MPa min	MPa	NBK provides a high guaranteed yield strength (~51 ksi), critical for load-bearing designs.
Elongation (A5)	4% min	22% min	%	Ductility is very low in the BK state; normalizing (NBK) restores considerable ductility.

Understanding St52 Conditions:

• BK (Hard): Maximizes strength through work hardening. Use when strength is the priority and little to no bending/forming is needed. Machinability might require adjustment.
• NBK (Normalized): Often the preferred condition. Normalizing after cold drawing provides an excellent mix: high yield strength (355 MPa / ~51 ksi minimum), good toughness, much improved ductility over BK, and generally good machinability for its strength level.
• BKS (Stress Relieved): Mainly retains the high strength/hardness of BK but reduces internal stresses, which can be important for stability during machining.
• GBK (Annealed): Used less often for St52 because it reduces the strength advantage. Specify only if maximum formability is the absolute priority.

Matching the condition (especially NBK for its balance) to the application is vital when working with St52 Steel Tubes.

How Seamless Precision Tubing is Made

Creating St52 Seamless Pipes that meet DIN 2391's precision requirements involves several controlled manufacturing stages:

1. Material Selection & Heating: It begins with solid steel billets confirmed to meet the St52 chemical specifications. These are heated uniformly in a furnace to make them pliable.
2. Piercing: A hole is forced through the center of the hot billet using specialized equipment (like a Mannesmann piercer), creating the initial seamless hollow.
3. Hot Rolling (Optional): The rough hollow might then pass through hot rolling mills to reduce its wall thickness and increase its length, bringing it closer to the dimensions needed for the next stage.
4. Surface Preparation: Before cold finishing, the tube surface usually undergoes cleaning (like pickling) to remove scale from hot forming. A clean surface is essential for good results in cold drawing.
5. Cold Drawing: This is the crucial step for precision. The tube is pulled through a hardened steel die at room temperature. An internal mandrel is often used at the same time to control the inner diameter precisely. This process accomplishes several things: it reduces the OD and wall to exact dimensions, creates a smooth surface, increases strength through work hardening, and improves straightness. Multiple passes might be needed.
6. Heat Treatment: After the final cold draw, the tube usually receives a specific heat treatment depending on the ordered condition. For St52, Normalizing (NBK) is common. This involves heating the tube uniformly and cooling it in controlled air to refine the grain structure and achieve the desired mechanical property balance. Other options are Annealing (GBK) or Stress Relieving (BKS). If ordered as BK, this step is omitted.
7. Finishing & Inspection: Final operations involve straightening to tight tolerances, cutting to required lengths, applying protective oils if specified, and conducting thorough inspections. These checks cover dimensions, surface condition, and verification of mechanical properties if testing was part of the order for the specified condition.

This careful process delivers the high strength, dimensional accuracy, and surface quality characteristic of DIN 2391 St52 Pipes.

Key Benefits of St52 Tubes & Pipes

Using St52 Tubes & Pipes, particularly those made to DIN 2391, offers significant advantages in demanding engineering contexts:

• Elevated Strength: St52 provides substantially higher yield and tensile strength compared to standard low-carbon steel grades (St35/St37), allowing for more robust designs or potential weight reduction by using thinner walls for the same load.
• Good Toughness: Especially in the normalized (NBK) condition, St52 offers good impact toughness, making it suitable for applications subject to dynamic loads or lower service temperatures (though not cryogenic).
• Dimensional Precision: Cold finishing ensures tight tolerances on diameters and wall thickness, which can simplify assembly, reduce machining requirements, and improve performance in applications like hydraulic cylinders.
• Smooth Surface Finish: The cold drawing process results in clean, smooth OD and ID surfaces, beneficial for seals, fluid flow, plating, or aesthetic purposes.
• Reliable Weldability: While being a higher strength steel, St52 generally maintains good weldability with appropriate procedures (like preheating for thicker sections), facilitating fabrication.
• Seamless Structural Integrity: The absence of a weld seam guarantees uniform material properties around the circumference, enhancing reliability under complex stresses.

Where St52 Tubing Finds Application

The combination of higher strength and precision makes DIN 2391 St52 Pipes suitable for more demanding roles than lower carbon grades:

• Hydraulic Cylinders: A very common use, especially honed St52 NBK for cylinder barrels, due to its high yield strength resisting pressure and buckling. Also used for high-strength piston rods.
• Heavy Machinery Components: Ideal for manufacturing robust axles, shafts, pivot pins, high-load bushings, rollers, and structural members in construction, mining, and agricultural equipment.
• Automotive Performance & Heavy Duty: Used in applications like performance suspension components, heavy truck chassis crossmembers, strong axles, and other parts where strength-to-weight is important.
• Cranes & Lifting Gear: Incorporated into structural elements of crane booms, supports, and hydraulic system components where high load capacity and safety factors are critical.
• Advanced Structural Engineering: Employed in specialized frameworks, supports, and architectural elements requiring dimensionally accurate tubes capable of handling significant stress.
• General Engineering: Serves as material for highly stressed machine parts, potentially gears (after surface hardening), robust tooling fixtures, and components where standard carbon steels lack sufficient strength or wear resistance.

St52 Seamless Pipes are the logical upgrade when design calculations show that St35 or St37 lack the necessary strength or when improved toughness is beneficial for the application's service conditions.

St52 Tubing Size Chart and Weight Chart

This chart gives nominal dimensions and estimated weights for several representative sizes of round St52 Tubes & Pipes. Use this data for planning; weights are theoretical.

OD (mm)	Wall (mm)	ID (mm)	Weight ( kg/m )	Weight (lbs/ft)	Notes
30.0	4.0	22.0	2.64	1.78
38.0	5.0	28.0	4.12	2.77
42.0	5.0	32.0	4.66	3.13	Common Hyd Size
45.0	6.0	33.0	5.79	3.90
50.0	7.0	36.0	7.69	5.17
55.0	5.0	45.0	6.27	4.21
60.0	8.0	44.0	10.4	7.00
65.0	7.5	50.0	11.0	7.39	Common Hyd Cyl
70.0	10.0	50.0	15.0	10.1	Heavy Wall
75.0	8.0	59.0	13.5	9.08
80.0	10.0	60.0	17.9	12.0	Common Hyd Cyl
90.0	10.0	70.0	19.9	13.4
100.0	12.0	76.0	27.0	18.1
110.0	10.0	90.0	25.1	16.9
125.0	12.5	100.0	35.4	23.8
140.0	15.0	110.0	47.4	31.8
160.0	18.0	124.0	64.7	43.5
180.0	20.0	140.0	79.8	53.6	Very Heavy Wall

Note: Weights derived from nominal dimensions using steel density (~7.85 g/cm³). Actual weights vary within tolerances.

Certifications and Compliance

Verification that St52 Tubes & Pipes meet the designated standards is crucial for demanding applications. USA Piping Solution ensures materials arrive with proper quality documentation.

• DIN 2391 / EN 10305-1 Compliance: Tubing is certified by the producer to meet the requirements of DIN 2391 or its EN equivalent for Grade St52 / E355. This covers chemical composition, seamless production, precision tolerances, and the mechanical properties associated with the ordered delivery condition (e.g., NBK).
• Mill Test Certificates (MTCs): Shipments include comprehensive MTCs, usually following EN 10204 Type 3.1 format. These provide full traceability (heat number) and report the actual chemical analysis results along with verified mechanical properties (yield, tensile, elongation) for the specific batch and condition supplied.
• ISO 9001 System: Our quality management practices adhere to ISO 9001 standards, ensuring consistent supplier vetting, documentation control, and handling procedures.
• Standard Markings: Tubes are marked according to standard practice, typically displaying:
• Manufacturer's mark
• Standard (DIN 2391 or EN 10305-1) and Grade (St52 or E355)
• Dimensions (OD x Wall)
• Delivery Condition (NBK, BKS, etc.)
• Heat Number.

This documentation package provides the necessary quality assurance for using St52 tubing in high-performance roles.
