Stainless Steel 310 Flanges Manufacturer & Supplier - USA Piping Solution

When operating conditions demand resilience against intense heat and corrosive attack, Stainless Steel 310 Flanges provide a proven, high-performance solution. Their ability to maintain strength at elevated temperatures, coupled with outstanding oxidation resistance, makes them essential in challenging sectors like heat treatment and power generation. USA Piping Solution is your dedicated source for a full selection of quality ASTM A182 F310 Flanges. We ensure every flange meets strict global standards, ready for your demanding applications. Trust us for reliable, certified SS 310 Flanges, backed by solid technical insight and attentive service. Discover why industries count on USA Piping Solution for their Stainless Steel 310 Flange needs.

Understanding Stainless Steel 310 Flanges

At their heart, Stainless Steel 310 Flanges are robust connectors forged from Grade 310 stainless steel. What gives this austenitic alloy its strength is a significant infusion of chromium (around 25%) and nickel (around 20%). This specific chemistry unlocks several key performance benefits:

• High-Heat Endurance: The material reliably maintains its structural integrity, making it suitable for continuous operation near 1050°C (1922°F).
• Oxidation Shield: Thanks to ample chromium, a tenacious protective oxide layer forms on the surface, crucial for longevity in equipment like furnaces and exhaust systems.
• Corrosion Toughness: Beyond heat, it offers good resistance against moderate carburization and sulfidation, particularly when temperatures are high.
• Inherent Durability: Like many austenitic steels, it remains tough across a wide temperature spectrum.

Key Variations to Note:

• SS 310S (UNS S31008): Lower carbon content enhances weldability and reduces the risk of sensitization during heat exposure, often preferred for cyclic temperature service.
• SS 310H (UNS S31009): A controlled higher carbon range boosts high-temperature strength and creep resistance, making it ideal for load-bearing components at heat.

USA Piping Solution supplies the full 310 family – including 310, 310S, and 310H (conforming to ASTM A182 F310/F310S/F310H) – ensuring the material properties align perfectly with your operational demands.

Exploring Types of Stainless Steel 310 Flanges

Choosing the right flange configuration is critical for a leak-free, maintainable system. USA Piping Solution provides diverse SS 310 Flanges to suit various connection needs:

Weld Neck (WNRF) Flanges

Often the preferred choice for critical applications, 310 Weld Neck Flanges are distinguished by a tapered hub. This design transfers stresses effectively into the pipe.

• The Connection: They are butt-welded directly to the pipe, creating a strong, continuous structure.
• Performance Edge: Excellent for high pressure/temperature cycles and situations involving significant stress. The smooth transition also benefits flow.
• Typical Environments: High-stakes process lines in refineries, chemical plants, and power facilities where reliability is non-negotiable.

Slip-On (SORF) Flanges

310 Slip-On Flanges slide over the pipe end before being welded internally and externally.

• The Connection: Secured with two fillet welds – one outside the hub, one inside the flange face.
• Practical Points: Generally offer a lower installed cost and can simplify alignment.
• Things to Consider: They have lower pressure ratings and fatigue strength compared to weld necks, making them less suitable for severe service.
• Typical Environments: Lower-pressure duties, utility systems, and general piping where cost-effectiveness is important.

Blind (BLRF) Flanges

Think of a Stainless Steel 310 Blind Flange as a solid cover plate, drilled for bolting. Its job is to seal off an opening.

• The Connection: Bolted securely to another flange, using a gasket to ensure a tight seal.
• Functionality: Used to terminate pipe runs, close vessel nozzles, or provide isolation points.
• Practical Points: Offers a robust closure method while allowing for potential future access.
• Typical Environments: End closures on piping, valves, and pressure vessels; creating maintenance breaks in a system.

Socket Weld (SWRF) & Threaded (NPT/BSPT) Flanges

These are common choices for smaller pipe diameters (usually NPS 2 and below) and often in lower-pressure contexts.

• Socket Weld: Features a recessed area (socket) to receive the pipe end, which is then fillet welded around the hub. Offers a smooth internal bore.
• Threaded: Equipped with internal threads that screw onto a threaded pipe end. This allows assembly without welding, useful where flames are restricted.

Additional Styles: Our inventory also includes Lap Joint (LJRF), Orifice, Spectacle Blind, and Reducing SS 310 Flanges.

Meeting SS 310 Flange Specifications

For reliable performance and interchangeability, our Stainless Steel 310 Flanges comply with essential international standards:

ASTM A182 / ASME SA182 F310

This is the foundational specification for forged stainless steel flanges designed for high-temperature applications.

• It details requirements for chemical composition, mechanical strength, heat treatment, and necessary testing.
• Look for the F310, F310S, F310H designations to confirm the specific grade.

Dimensional Standards (ANSI, BS, DIN, EN)

These standards govern the physical dimensions, pressure handling capacity, tolerances, marking, and face types:

• ANSI/ASME B16.5: The primary North American standard for flanges up to NPS 24 (Classes 150-2500). An ANSI B16.5 310 Flange conforms to this.
• ASME B16.47: Addresses larger diameter flanges (NPS 26-60).
• BS, DIN, EN 1092-1: Important British, German, and harmonized European standards, often using PN pressure ratings.

We provide flanges across various pressure classes (150#-2500#, PN6-PN64+) and with different sealing faces (RF, FF, RTJ).

Understanding Composition and Mechanical Strength

The impressive capabilities of SS 310 Flanges arise directly from their well-defined chemistry and the physical properties that result:

Chemical Makeup (Typical Weight %)

Grade	C	Mn	Si	P	S	Cr	Ni	Fe
310	0.25 max	2.0 max	1.5 max	0.045 max	0.030 max	24.0-26.0	19.0-22.0	Bal.
310S	0.08 max	2.0 max	1.5 max	0.045 max	0.030 max	24.0-26.0	19.0-22.0	Bal.
310H	0.04-0.10	2.0 max	1.0 max	0.045 max	0.030 max	24.0-26.0	19.0-22.0	Bal.

Physical Attributes (Typical, Room Temp, Annealed)

Property	Grade 310 / 310S / 310H
Tensile Strength, min	515 MPa (75 ksi)
Yield Strength (0.2%), min	205 MPa (30 ksi)
Elongation in 2", min	40 %
Hardness, max	RB 95 / BHN 217
Melting Range	1400-1450°C (2550-2650°F)
Density	~7.9-8.0 g/cm³

While these figures show good baseline strength, the true value of ASTM A182 F310 Flanges lies in retaining significant strength at high temperatures, alongside top-tier oxidation and creep resistance. This combination makes them suitable for truly demanding service.

Where SS 310 Flanges Excel: Applications & Industries

The unique profile of SS 310 Flanges makes them vital across industries grappling with heat and corrosion:

• Heat Treating: Essential for furnace structures, muffles, conveyor parts, baskets, and fixtures enduring thermal cycles.
• Refining & Petrochemicals: Found in cracker units, reformers, flare systems, and high-temperature boiler applications.
• Power Generation: Used in combustors, boiler supports, burners, and coal gasification systems.
• Chemical Processing: Suitable for handling certain hot, aggressive chemicals or salts (always confirm specific compatibility).
• Metallurgy & Mining: Employed in kilns, smelters, and refining equipment facing intense heat.
• Cement Manufacturing: Key components in kilns and related high-temperature zones.

Navigating the Stainless Steel 310 Flange Size Chart

USA Piping Solution offers SS 310 Flanges covering a wide spectrum of sizes and pressure capabilities:

• Common Sizes: Stock ranges from NPS ½” (15 NB) up to 48” (1200 NB), with possibilities for sourcing larger dimensions.
• Pressure Handling: Includes standard ANSI Classes (150# to 2500#) and common PN ratings (PN6 to PN64+).
• Styles & Faces: We provide all major configurations (Weld Neck, Slip-On, Blind, etc.) and sealing faces (RF, FF, RTJ).

For precise dimensional data tailored to your project's needs (specific size, class, standard like ANSI B16.5 310 Flange), please connect with our sales experts or request a detailed quote.

Our Commitment: Certifications and Quality Assurance

At USA Piping Solution, quality isn't just a step; it's ingrained. We ensure our SS 310 Flanges meet stringent quality benchmarks:

• Full Traceability: We maintain records allowing materials to be traced back to their origin.
• Verified Test Reports: Mill Test Certificates (MTRs to EN 10204 3.1) are available, confirming material properties.
• Standards Guarantee: We assure compliance with all specified industry standards (ASTM, ASME, ANSI, etc.).
• Optional Third-Party Inspection: We can facilitate TPI by recognized agencies upon request.
• ISO 9001 Framework: Our quality management system ensures process consistency.
• Rigorous Checks: Each flange undergoes thorough visual and dimensional verification before shipment.

This focus means you receive ASTM A182 F310 Flanges ready for dependable, safe deployment.

Why Partner with USA Piping Solution for SS 310 Flanges?

Choosing USA Piping Solution means accessing key advantages:

1. Ready Availability: Our substantial inventory often translates to faster project starts.
2. Expert Guidance: Leverage our team's experience to select the best product fit.
3. Reliable Quality: We source responsibly and provide full documentation for peace of mind.
4. Sound Value: Expect competitive pricing without compromising on essential quality.
5. Efficient Logistics: We're geared for prompt delivery across the US and internationally.
6. Focused Support: Experience responsive communication and service tailored to your needs.
7. Streamlined Sourcing: Find a wide range of related piping products under one roof.

Explore Related Piping Products

Complete your project needs with our other available materials:

Take the Next Step

Need flanges engineered for extreme heat and challenging conditions? USA Piping Solution provides premium Stainless Steel 310 Flanges, backed by expertise and reliable service.

Contact USA Piping Solution today. We can discuss your application, provide detailed specifications, or generate a competitive quote for your Stainless Steel 310 Flanges.

Depend on USA Piping Solution for your critical ASTM A182 F310 Flange requirements.

Request Your Stainless Steel 310 Flanges Quote Today!
